MFP2-SFB
MFP2-SFB
MFP2-SFB
Solar Powered Charging
BLE 5.1 for sensor monitoring
Rare Earth Magnets
Vast Usage
Solar Powered Charging
BLE 5.1 for sensor monitoring
Rare Earth Magnets
Features & Benefits
- Solar Power Charging
- Internal Battery
(up to 10.5 months battery life) - IP67 Waterproof
- Long Term Deployments
- Real-Time Monitoring
- Alerts/Notifications
Rare Earth Magnets for a durable mounting solution
Location Management
Save Time
Increase Asset Utilization
Theft Prevention
- Solar Power Charging
- Internal Battery
(up to 10.5 months battery life) - IP67 Waterproof
- Long Term Deployments
- Real-Time Monitoring
- Alerts/Notifications
Rare Earth Magnets for a durable mounting solution
Location Management
Save Time
Increase Asset Utilization
Theft Prevention
Detailed Summary
The MFP2-SFB is a solar powered asset tracker that features superior GPS performance and a 9600mAh internal-rechargeable battery. The MFP2-SF is designed to be a complete long term deployment tracker suitable for monitoring and locating assets or equipment/trailers/trucks/containers that are stationary or on the move. Its IP67 waterproof enclosure can withstand harsh weather environments and its internal battery can be charged by its solar panel to help lower maintenance cost. The superior internal cellular and GPS antennas eliminate the need for external antennas making the MFP2-SFB easily mountable.
Detailed Summary
The MFP2-SFB is a solar powered asset tracker that features superior GPS performance and a 9600mAh internal-rechargeable battery. The MFP2-SF is designed to be a complete long term deployment tracker suitable for monitoring and locating assets or equipment/trailers/trucks/containers that are stationary or on the move. Its IP67 waterproof enclosure can withstand harsh weather environments and its internal battery can be charged by its solar panel to help lower maintenance cost. The superior internal cellular and GPS antennas eliminate the need for external antennas making the MFP2-SFB easily mountable.
Device Behavior:
Reporting Frequency:
1 time every 5 minutes while in motion
1 time every 1 hour when stationary
Installation Time: <20 Minutes
The MFP2-SFB supports:
- Motion Detection
- Device Battery Status
- GPS Location
- GPS Speed
- Geo-Fence
- Device-Side Logged Messages
Device Supports:
- Internal Antennas
- Magnetic Charging Port
- LED Indicator: Network, GNSS and Battery
Specifications:
Waterproof: IP67
Dimensions: 3.35in x 7.28in x 1.22in
Weight: 13.05oz
Battery: Rechargeable Li 9600 mAh/3.6V
Battery Life: Standby Time (without considering solar charging, 2 hours active tracking per day)
5 minutes reporting: 170 Days
Charging & Data Communication: Magnetic USB cable (recommend using 5V 1A adapter, 10 hours charging time)
Solar Panel: Used for charging tracker internal battery
Operating Temperature: -25℃ ~ +70℃ (-13°F ~ 158°F)
Mounting: Magnets/Screws
Accessories:
Included:
- USB Cable: Charging
- Screws (Mounting)
Optional:
- Magnets (Mounting)
Device Behavior:
Reporting Frequency:
1 time every 5 minutes while in motion
1 time every 1 hour when stationary
Installation Time: <20 Minutes
The MFP2-SFB supports:
- Motion Detection
- Device Battery Status
- GPS Location
- GPS Speed
- Geo-Fence
- Device-Side Logged Messages
Device Supports:
- Internal Antennas
- Magnetic Charging Port
- LED Indicator: Network, GNSS and Battery
Specifications:
Waterproof: IP67
Dimensions: 3.35in x 7.28in x 1.22in
Weight: 13.05oz
Battery: Rechargeable Li 9600 mAh/3.6V
Battery Life: Standby Time (without considering solar charging, 2 hours active tracking per day)
5 minutes reporting: 170 Days
Charging & Data Communication: Magnetic USB cable (recommend using 5V 1A adapter, 10 hours charging time)
Solar Panel: Used for charging tracker internal battery
Operating Temperature: -25℃ ~ +70℃ (-13°F ~ 158°F)
Mounting: Magnets/Screws
Accessories:
Included:
- USB Cable: Charging
- Screws (Mounting)
Optional:
- Magnets (Mounting)
